Geometry

  XS S M ML L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 348 338 414 344 390 373
Stack 550 440 593 626 515 673
Top Tube (effective) 414 519 592 667 634 636
Seat Tube C-T 445 387 544 547 555 463
Head Angle 58 78 71 65 71 60
Seat Angle 73 63 77 81 82 71
Head Tube 98 87 141 124 141 166
Chainstay 387 438 451 381 486 397
Wheelbase 1065 1050 1128 871 1215 1033
Front Centre 586 495 565 731 737 616
Standover 724 814 646 900 794 792
BB Drop 83 85 88 73 85 79
Fork Rake / Offset 56 63 47 41 59 51
Trail 67 61 65 54 72 61
Fork Length (A2C) 424 457 322 471 466 437
Tyre Max Width 41 52 47 53 55
Rider Height <163 161–170 168–177 175–184 182–192 >190
Frame Weight 799 743 895 685 968 1058
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer
