Geometry

  49 52 54 56 58 61
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 421 327 468 389 391 421
Stack 518 635 462 531 520 500
Seat Tube C-T 481 469 568 552 513 600
Head Angle 72 75 74 61 62 81
Seat Angle 81 68 67 67 87 79
Chainstay 409 374 467 442 462 450
Wheelbase 1177 983 852 1148 1134 1170
Standover 811 864 951 738 901 1017
BB Drop 89 88 90 93 83 76
Fork Rake / Offset 46 54 41 41 48 49
Trail 68 72 64 66 52 69
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
