Geometry

  49 52 54 56 58
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 392 413 424 356 450
Stack 480 524 602 463 492
Top Tube (effective) 420 482 502 556 569
Seat Tube C-T 370 441 553 623 619
Head Angle 58 65 76 74 71
Seat Angle 79 65 82 74 76
Wheelbase 993 845 992 806 894
Front Centre 560 681 552 630 567
BB Drop 63 64 65 70 82
BB Type T47 T47 T47 T47 T47
Fork Rake / Offset 63 43 39 44 46
Trail 52 54 65 49 57
Fork Length (A2C) 422 390 346 362 416
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
