Geometry

  48cm 51cm 54cm 56cm 59cm
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 354 310 358 355 411
Stack 499 612 588 487 655
Top Tube (effective) 488 540 457 652 703
Seat Tube C-T 379 490 404 596 553
Head Angle 71 78 70 78 76
Seat Angle 66 59 72 61 83
Head Tube 108 128 124 153 188
Chainstay 421 439 449 440 369
Wheelbase 837 939 1001 825 920
Front Centre 672 499 627 471 713
Standover 786 699 689 956 989
Max Post Insertion 121 138 171 149 154
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
