Geometry

  XS (49) S (52) M (54) L (56) XL (58) XXL (61)
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 324 338 430 438 421 385
Stack 482 452 573 678 651 510
Top Tube (effective) 514 486 462 589 521 627
Seat Tube C-T 399 421 502 469 626 472
Head Angle 73 72 58 64 76 79
Seat Angle 66 62 77 64 72 86
Head Tube 73 92 117 126 147 139
Chainstay 410 379 432 468 473 505
Wheelbase 1103 826 1217 977 878 1103
Front Centre 546 689 575 719 627 704
Standover 773 879 837 830 751 919
BB Drop 74 83 81 68 64 73
BB Height 234 244 310 307 254 232
Fork Rake / Offset 53 51 57 40 48 51
Trail 83 67 79 73 79 74
Fork Length (A2C) 490 347 367 408 427 343
Rider Height 155–163 163–170 170–175 175–180 180–188 188–196
Pad Stack 529 688 620 525 557 668
Pad Reach 428 429 638 458 590 540
Data Source Velo Velo Velo Velo Velo Velo

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
