Geometry

  XXS | 44 XS | 49 S | 52 M | 54 L | 56 XL | 58 XXL | 61
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 309 430 354 384 327 335 326
Stack 431 587 559 486 572 682 599
Top Tube (effective) 510 407 484 455 553 538 656
Seat Tube C-T 489 515 500 461 419 455 519
Head Angle 60 76 67 82 84 74 88
Seat Angle 64 69 64 73 66 79 82
Head Tube 74 115 117 148 172 165 250
Chainstay 484 380 467 425 425 352 455
Wheelbase 1107 1127 886 952 1002 1154 1013
Standover 845 731 750 885 898 865 755
BB Drop 79 89 84 64 74 78 79
BB Height 250 294 261 246 227 306 311
Fork Rake / Offset 56 58 43 38 51 38 37
Trail 59 69 57 53 65 45 44
Fork Length (A2C) 330 365 403 405 331 319 454
Seatpost Length 281 247 226 364 368 336 357
Stem Length 99 105 103 104 87 131 97
Crank Length 144 171 167 174 178 196 174
Bike Weight 6.48kg
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
