Geometry

  MD LG XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 444 372 445
Stack 733 696 612
Top Tube (effective) 591 569 704
Seat Tube C-T 499 528 538
Head Angle 75 64 77
Seat Angle 79 79 80
Head Tube 124 201 208
Chainstay 435 446 548
Wheelbase 1010 1049 1087
Front Centre 678 739 707
BB Drop 61 66 62
BB Height 308 356 335
Fork Rake / Offset 41 36 41
Trail 85 88 98
Wheel Size 23 32 30
Tyre Max Width 32 27 23
Data Source roadbikedatabase.com roadbikedatabase.com roadbikedatabase.com

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
