Geometry

  S(50cm) S/M(52cm) M(54cm) M/L(56cm) L(58cm) L/XL(60cm)
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 327 394 397 446 448 452
Stack 506 616 538 629 577 618
Top Tube (effective) 425 620 574 496 645 641
Seat Tube C-T 519 498 535 518 660 655
Seat Tube (effective) 56 52 56 46 61 51
Head Angle 68 65 60 81 75 79
Seat Angle 81 84 68 83 67 82
Head Tube 123 100 126 167 158 194
Chainstay 464 373 484 370 397 387
Wheelbase 1057 1036 1107 947 1066 1166
Standover 660 826 749 690 703 799
BB Drop 63 63 69 80 55 81
BB Height 226 258 298 216 213 289
Fork Rake / Offset 50 46 40 39 39 38
Handlebar Width 383 395 389 431 430 379
Stem Length 72 108 103 124 90 105
Crank Length 197 188 169 152 198 146
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer
