Geometry

  XS S M ML L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 304 316 353 322 317 361
Stack 466 612 604 514 515 736
Top Tube (effective) 472 486 573 517 640 555
Seat Tube C-T 421 516 464 611 611 611
Head Angle 77 79 78 83 76 81
Seat Angle 86 67 69 81 72 70
Head Tube 111 121 146 154 174 237
Chainstay 431 447 356 355 354 484
Wheelbase 1172 1112 1109 1191 1041 1236
Standover 701 830 729 869 959 686
BB Drop 68 76 79 57 81 58
Fork Rake / Offset 40 57 46 58 48 48
Trail 76 70 52 51 69 65
Wheel Size 700C 700C 700C 700C 700C 700C
Handlebar Width 479 462 394 341 484 496
Stem Length 77 98 90 97 131 116
Crank Length 161 184 157 140 141 193
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Measurements are in millimeters and degrees.
