Geometry

  XS/42.5 S/44.5 M/47.0 M/L/50.0 L/52.5
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 378 306 425 371 369
Stack 563 496 652 537 475
Top Tube (effective) 482 458 576 632 683
Head Angle 71.0° 72.5° 73.0° 73.0° 73.0°
Seat Angle 74.5° 73.5° 73.0° 73.0° 73.0°
Head Tube 144 117 166 156 160
Chainstay 428 399 389 347 337
Wheelbase 1135 938 1020 930 902
Standover 736 807 667 649 879
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Note: Compact frame

Measurements are in millimeters and degrees.
