Geometry

  S/50 M/52.5 ML/54.5 L/55.5
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 321 344 401
Stack 637 648 626
Top Tube (effective) 430 520 465 632
Head Angle 71.0° 71.5° 72.0° 72.5°
Seat Angle 73.5° 73.0° 73.0° 73.0°
Head Tube 151 159 145 201
Chainstay 484 374 344 436
Wheelbase 860 1158 1183 1171
Standover 779 800 936 701
BB Drop 63
Data Source Manufacturer Measured own bike Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
