Geometry

  XS S M ML L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 340 324 408 377 434 417
Stack 518 506 634 473 461 501
Top Tube (effective) 413 580 570 660 579 695
Seat Tube C-T 366 397 582 452 428 486
Head Angle 80 76 79 60 64 66
Seat Angle 67 82 67 76 81 70
Head Tube 118 104 132 161 193 207
Chainstay 410 407 367 358 335 439
Wheelbase 808 1021 852 801 1187 890
Front Centre 514 458 457 697 545 498
Standover 803 824 636 822 963 867
BB Drop 66 77 66 70 78 69
Fork Length (A2C) 400 396 379 311 366 414
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
