Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 352 375 449 333 417
Stack 446 460 572 515 632
Top Tube (effective) 535 462 595 500 699
Seat Tube C-T 397 387 597 500 665
Head Angle 74 72 78 83 64
Seat Angle 82 74 85 75 81
Head Tube 101 149 169 199 227
Chainstay 418 391 441 352 503
Wheelbase 868 1103 1235 1251 1045
Front Centre 538 607 620 595 738
Standover 745 724 780 820 1033
BB Drop 63 79 78 87 70
Fork Rake / Offset 42 59 55 53 52
Trail 97 82 87 53 60
Fork Length (A2C) 369 398 332 402 380
Data Source

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
