Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 453 495 348
Top Tube (effective) 604 492 652 625
Seat Tube C-T 425 543 547 630
Head Angle 69 74 62 69
Seat Angle 81 74 66 76
Head Tube 92 115 96 113
Chainstay 378 411 483 466
Wheelbase 1091 1209 1268 1073
Standover 838 731 620 854
BB Drop 64 74 63 56
BB Type Cartridge Cartridge Cartridge Cartridge
Fork Rake / Offset 41 45 48 47
Fork Length (A2C) 468 579 617 420
Seatpost Diameter 34 36 31 35
Wheel Size 29" 29" 29" 29"
Handlebar Width 651 934 894 737
Stem Length 57 53 66 59
Crank Length 201 157 203 142
Seat Clamp 33 35 36 38
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
