Geometry

  S M L XL XXL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 314 372 394 393 372
Stack 615 515 532 480 548
Top Tube (effective) 437 516 497 573 666
Seat Tube C-T 516 477 508 542 673
Head Angle 75 66 63 78 59
Seat Angle 68 80 59 66 58
Head Tube 133 150 161 196 232
Chainstay 460 408 468 486 454
Wheelbase 989 1122 905 1181 1132
Front Centre 590 588 663 581 639
BB Drop 68 67 70 63 85
Fork Rake / Offset 43 48 48 52 37
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements

Also! Search by Stack and Reach

You can now search the database by numbers.

Find bikes that match your geometry criteria.
