Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 395 498 477 439
Stack 457 511 585 504
Top Tube (effective) 531 520 668 744
Seat Tube C-T 433 364 512 576
Head Angle 69 58 69 55
Seat Angle 87 78 71 79
Head Tube 75 82 102 92
Chainstay 497 432 502 517
Wheelbase 906 1029 983 1376
Front Centre 600 692 672 620
Standover 635 893 792 706
BB Drop 44 40 33 42
BB Height 348 301 373 350
BB Type BB92 BB92 BB92 BB92
Fork Rake / Offset 38 43 38 39
Fork Length (A2C) 438 571 586 454
Seatpost Diameter 28 36 33 30
Axle Spacing 125 164 123 131
Wheel Size 29" 29" 29" 29"
Handlebar Width 667 853 851 864
Stem Length 42 45 59 49
Crank Length 152 142 191 183
Front Travel 100 101 111 115
Rear Travel 104 114 118 105
Shock Size 165x40 165x40 165x40 165x40
Front Mech none none none none
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Note: The factory build has a 55mm stem

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
