Geometry

  49 52 54 56 58
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 445 379 425 469 363
Stack 505 508 652 525 579
Top Tube (actual) 603 482 480 541 524
Seat Tube C-T 503 467 577 515 509
Head Angle 79 75 60 86 63
Seat Angle 79 85 69 75 59
Head Tube 109 101 126 162 153
Chainstay 329 450 448 346 416
Wheelbase 861 1065 855 886 993
Front Centre 554 633 557 639 703
BB Drop 78 76 83 70 76
BB Type BB86 BB86 BB86 BB86 BB86
Fork Rake / Offset 53 40 52 50 49
Tyre Max Width 33 28 32 27 32
Rider Height 166-172 172-178 178-184 184-190 190-196
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
