Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 323 389 402 487
Stack 705 515 692 756
Top Tube (effective) 606 648 530 581
Seat Tube C-T 399 488 484 578
Head Angle 73 77 76 82
Seat Angle 70 77 75 69
Head Tube 108 132 137 122
Chainstay 505 395 498 398
Wheelbase 1242 1077 1066 1031
BB Drop 67 48 69 51
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
