Geometry

  X-Small Small Medium Large X-Large
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 295 423 349 354 360
Stack 624 633 539 582 539
Top Tube (actual) 556 458 475 531 487
Seat Tube C-T 420 466 638 641 704
Head Angle 56 76 75 81 71
Seat Angle 64 85 60 76 66
Head Tube 97 152 128 197 195
Chainstay 503 437 379 411 340
Wheelbase 1021 1118 1198 1167 1076
BB Drop 80 89 82 86 65
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements
