Geometry

  XSM SML MED LRG XLG
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Top Tube (effective) 467 619 567 611 692
Seat Tube C-T 531 470 580 600 660
Head Angle 59 69 70 61 78
Seat Angle 82 82 76 70 77
Head Tube 104 103 121 120 165
Chainstay 448 465 395 474 321
BB Drop 79 75 63 64 59
Fork Rake / Offset 46 45 43 41 40
Fork Length (A2C) 436 332 378 302 386
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
