Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 457 505 498 594
Stack 648 735 706 795
Top Tube (effective) 691 588 549 580
Seat Tube C-T 356 383 368 430
Head Angle 74 56 70 61
Seat Angle 67 66 83 66
Head Tube 87 106 145 156
Chainstay 349 345 418 460
Wheelbase 965 1391 1113 1048
BB Drop 47 54 54 65
Wheel Size 31 23 30 29
Front Travel 166 156 164 149
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Measurements are in millimeters and degrees.
