| Small | Medium | Large | X-Large | |
|---|---|---|---|---|
| Add to Compare | ||||
| Reach | 427 | 528 | 527 | 508 |
| Stack | 549 | 654 | 683 | 636 |
| Top Tube (effective) | 651 | 587 | 545 | 725 |
| Top Tube (actual) | 603 | 564 | 655 | 654 |
| Seat Tube C-T | 358 | 431 | 473 | 574 |
| Head Angle | 67 | 60 | 75 | 61 |
| Seat Angle | 87 | 66 | 65 | 92 |
| Head Tube | 101 | 116 | 120 | 129 |
| Chainstay | 458 | 432 | 447 | 378 |
| Wheelbase | 1218 | 1077 | 1412 | 1334 |
| Standover | 794 | 864 | 734 | 898 |
| BB Drop | 22 | 27 | 29 | 23 |
| BB Height | 329 | 283 | 309 | 318 |
| Wheel Size | 34 | 27 | 23 | 31 |
| Pad Reach | 497 | 506 | 457 | 495 |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Note: Geometry table in slack configuration
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
