Geometry

  S - 51cm M - 53cm ML - 55cm L - 57cm XL - 59cm XXL - 61cm
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 395 344 357 405 433 369
Stack 540 617 466 654 680 626
Top Tube (effective) 434 477 559 661 579 569
Seat Tube C-C 429 500 553 531 574 561
Head Angle 78 60 78 71 70 82
Seat Angle 73 65 82 58 87 68
Head Tube 86 89 101 161 176 154
Chainstay 493 463 462 371 440 421
BB Drop 90 93 77 95 78 94
Fork Rake / Offset 54 46 48 43 55 55
Fork Length (A2C) 383 379 378 348 454 330
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
