Geometry

  S M M/L L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 318 364 345 454 442
Stack 569 525 626 522 520
Top Tube (effective) 523 625 633 671 680
Seat Tube C-T 556 475 547 454 464
Head Angle 71 72 77 72 69
Seat Angle 67 75 64 77 80
Head Tube 90 142 144 138 208
Chainstay 421 467 442 437 415
Wheelbase 1212 1030 1213 901 889
Front Centre 501 613 547 706 706
Standover 818 871 660 731 731
BB Drop 72 73 57 84 75
Fork Rake / Offset 51 46 48 58 49
Trail 51 55
Data Source Litespeed Litespeed Litespeed Litespeed Litespeed

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
