Geometry

  XS S M ML L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 403 451 322 387 435 343
Stack 497 514 662 630 603 647
Top Tube (effective) 550 439 564 636 641 621
Seat Tube C-T 363 448 511 539 601 640
Head Angle 70 71 68 68 80 58
Seat Angle 60 84 79 84 77 82
Head Tube 110 79 135 169 145 183
Chainstay 463 439 393 376 500 386
Wheelbase 969 1062 1173 1039 1031 883
Front Centre 657 537 511 506 665 615
Standover 832 814 740 865 664 863
BB Drop 86 63 62 82 79 69
Fork Rake / Offset 45 42 44 46 41 43
Stem Length 679 878 916 921 1018 1284
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
