Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 444 361 390 325
Stack 484 611 683 534
Top Tube (effective) 495 570 497 513
Seat Tube C-T 531 613 632 658
Head Angle 57 58 72 63
Seat Angle 65 83 67 63
Head Tube 97 100 116 149
Chainstay 426 482 418 447
Wheelbase 1140 960 967 875
Front Centre 481 648 573 600
BB Drop 71 70 57 73
Fork Rake / Offset 49 44 58 56
Seatpost Length 385 385 282 280
Handlebar Width 337 359 367 455
Stem Length 74 81 109 110
Crank Length 141 143 183 187
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
