Geometry

  S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 310 436 389 386
Stack 535 509 622 750
Top Tube (effective) 564 466 513 672
Seat Tube C-T 459 422 575 655
Head Angle 72 80 71 78
Seat Angle 61 80 64 84
Head Tube 96 166 157 245
Chainstay 470 395 395 420
Wheelbase 925 897 972 1185
Standover 701 763 618 732
BB Drop 90 85 75 90
BB Height 301 241 277 312
Handlebar Width 564 689 699 690
Stem Length 67 65 56 69
Crank Length 178 172 181 152
Rider Height 157 – 168 cm 168 – 178 cm 178 – 188 cm 185 – 194 cm
Data Source Marin Marin Marin Marin

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
