Geometry

  s m l
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 440 431 478
Stack 545 671 617
Top Tube (effective) 604 468 687
Seat Tube C-T 440 472 497
Head Angle 69.5° 69.5° 69.5°
Seat Angle 74° 74° 74°
Head Tube 125 179 212
Chainstay 373 389 395
Wheelbase 1169 960 1088
BB Drop 84 76 87
BB Height 331 307 285
Handlebar Width 539 704 591
Stem Length 62 68 79
Crank Length 175 202 170
Data Source Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
