Geometry

  S M L
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 367 394 387
Stack 641 526 640
Top Tube (effective) 582 666 598
Seat Tube C-T 341 438 517
Head Angle 58 69 67
Seat Angle 87 85 71
Head Tube 226 185 236
Chainstay 523 459 424
Wheelbase 1236 1295 913
Standover 462 437 598
BB Drop 70 62 74
BB Height 329 272 251
Fork Rake / Offset 44 48 50
Seatpost Diameter 32 28 29
Wheel Size 700C 700C 700C
Handlebar Width 584 780 726
Stem Length 36 43 47
Crank Length 184 151 201
Data Source Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
