Geometry

  S M L
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 403 357 457
Stack 647 649 721
Top Tube (effective) 640 557 619
Seat Tube C-T 459 495 597
Head Angle 75 71 72
Seat Angle 85 74 72
Head Tube 153 202 184
Chainstay 436 446 357
Wheelbase 910 994 909
Standover 525 584 662
BB Drop 86 84 71
BB Height 258 278 272
Fork Rake / Offset 44 49 53
Seatpost Diameter 28 32 23
Handlebar Width 679 672 703
Stem Length 73 72 84
Crank Length 144 170 164
Data Source Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
