Geometry
| Add to Compare |
| Reach |
| Stack |
| Top Tube (effective) |
| Top Tube (actual) |
| Seat Tube C-T |
| Seat Tube C-C |
| Head Angle |
| Head Tube |
| Chainstay |
| Wheelbase |
| Front Centre |
| Standover |
| BB Drop |
| Fork Rake / Offset |
| Trail |
| Fork Length (A2C) |
| Axle Spacing |
| Handlebar Width |
| Stem Length |
| Crank Length |
| Rider Height |
| Frame Weight |
| Data Source |
| S | M | L | XL | |
|---|---|---|---|---|
| Add to Compare | ||||
| Reach | 402 | 402 | 411 | 483 |
| Stack | 682 | 516 | 559 | 582 |
| Top Tube (effective) | 611 | 671 | 603 | 546 |
| Top Tube (actual) | 608 | 466 | 522 | 685 |
| Seat Tube C-T | 348 | 481 | 420 | 501 |
| Seat Tube C-C | 395 | 337 | 382 | 392 |
| Head Angle | 79 | 80 | 79 | 75 |
| Head Tube | 102 | 90 | 96 | 120 |
| Chainstay | 487 | 383 | 413 | 468 |
| Wheelbase | 901 | 1021 | 1326 | 1219 |
| Front Centre | 776 | 604 | 658 | 660 |
| Standover | 849 | 758 | 898 | 653 |
| BB Drop | 59 | 60 | 66 | 55 |
| Fork Rake / Offset | 49 | 42 | 48 | 38 |
| Trail | 106 | 98 | 116 | 121 |
| Fork Length (A2C) | 484 | 536 | 417 | 541 |
| Axle Spacing | 138 | 141 | 129 | 150 |
| Handlebar Width | 728 | 679 | 749 | 755 |
| Stem Length | 59 | 59 | 60 | 56 |
| Crank Length | 153 | 192 | 195 | 201 |
| Rider Height | 162-170 | 168-180 | 178-188 | 186-198 |
| Frame Weight | 1875gr | 1880gr | 1890gr | 1910gr |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Select
two sizes then 'Compare'
two sizes then 'Compare'Measurements are in millimeters and degrees.
