Geometry

  XS S S/M M/L L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 312 323 446 333 468 464
Stack 428 527 637 541 479 693
Top Tube (effective) 571 525 595 631 504 569
Seat Tube C-C 513 493 597 463 503 699
Head Angle 71 75 64 65 65 73
Seat Angle 74 86 75 71 77 83
Head Tube 115 113 161 183 202 222
Chainstay 407 459 383 410 429 407
Wheelbase 944 995 977 1029 845 973
Standover 744 691 798 696 691 812
BB Drop 54 70 70 57 61 58
Fork Length (A2C) 349 420 321 346 348 393
Rider Height < 167 163 - 172 168 - 177 173 - 182 178 - 187 > 183
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
