Geometry

  3XS XXS XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 394 371 379 382 370 379 344
Stack 484 418 590 529 496 596 482
Top Tube (effective) 486 445 576 585 489 675 535
Seat Tube C-T 491 545 479 558 635 516 587
Head Angle 82 81 80 63 68 85 61
Seat Angle 64 60 70 74 63 74 87
Head Tube 105 106 130 150 139 148 159
Chainstay 446 411 382 420 333 419 430
Wheelbase 1160 923 1161 1005 1115 1160 943
Standover 720 686 833 658 699 843 995
BB Drop 71 61 76 76 57 75 61
Fork Length (A2C) 369 360 352 460 351 357 423
Wheel Size 28" 28" 28" 28" 28" 28" 28"
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
