Geometry

  XXS XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 371 408 434 349 467 487
Stack 553 612 576 611 561 679
Top Tube (effective) 470 457 458 567 682 555
Seat Tube C-C 381 581 430 443 496 526
Head Angle 69 79 72 72 77 72
Seat Angle 64 80 76 81 67 74
Head Tube 97 117 131 159 175 156
Chainstay 329 344 330 458 333 362
Wheelbase 892 814 865 877 823 836
Standover 890 727 738 815 986 862
BB Drop 66 72 60 63 75 58
Fork Length (A2C) 423 333 321 379 423 318
Wheel Size 28" 28" 28" 28" 28" 28"
Tyre Max Width 30mm 30mm 30mm 30mm 30mm 30mm
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
