Geometry

  XS (49) S (52) M (54) L (56) XL (58)
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 314 339 379 458 322
Stack 488 518 499 535 547
Top Tube (effective) 513 579 646 594 644
Seat Tube C-T 512 509 473 478 626
Head Angle 67 76 65 71 73
Seat Angle 72 85 81 75 83
Head Tube 92 141 140 133 163
Chainstay 489 407 424 458 462
Wheelbase 1003 1196 1153 1028 1033
Front Centre 533 553 660 666 668
BB Drop 77 90 62 80 77
BB Type PF41 PF41 PF41 PF41 PF41
Fork Rake / Offset 43 40 55 59 55
Fork Length (A2C) 364 410 376 372 461
Seatpost Diameter 23 23 30 31 30
Tyre Max Width 41 48 53 37 42
Seatpost Length 404 384 389 289 368
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer
