Geometry

  XXS (46) XS (49) S (52) M (54) L (56) XL (58)
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 402 358 366 411 349 479
Stack 516 586 562 575 502 637
Top Tube (effective) 402 520 513 586 657 673
Seat Tube C-T 393 408 549 575 578 551
Head Angle 75 70 69 73 75 68
Seat Angle 88 74 87 67 59 60
Head Tube 101 90 137 149 171 159
Chainstay 433 340 401 357 368 354
Wheelbase 1050 930 808 1021 836 1031
Front Centre 674 522 551 589 686 599
BB Drop 69 58 68 73 72 68
BB Type PF41 PF41 PF41 PF41 PF41 PF41
Fork Rake / Offset 53 51 45 53 39 45
Fork Length (A2C) 372 395 417 379 353 444
Seatpost Diameter 29 26 32 25 27 27
Wheel Size 598 754 562 752 835 801
Tyre Max Width 32 36 27 35 27 30
Seatpost Length 281 400 351 317 376 345
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer
