Geometry
| 49 | 52 | 54 | 56 | 59 | |
|---|---|---|---|---|---|
| Add to Compare | |||||
| Reach | 413 | 445 | 431 | 469 | 450 |
| Stack | 573 | 578 | 534 | 499 | 665 |
| Top Tube (effective) | 448 | 597 | 570 | 583 | 561 |
| Seat Tube C-C | 488 | 392 | 570 | 465 | 537 |
| Head Angle | 76 | 80 | 70 | 67 | 62 |
| Seat Angle | 69 | 71 | 71 | 75 | 58 |
| Head Tube | 119 | 114 | 118 | 171 | 165 |
| Chainstay | 428 | 474 | 352 | 373 | 431 |
| Wheelbase | 1090 | 867 | 803 | 1062 | 1124 |
| Front Centre | 485 | 625 | 502 | 531 | 567 |
| BB Drop | 57 | 77 | 61 | 76 | 71 |
| BB Type | T47 | T47 | T47 | T47 | T47 |
| Fork Rake / Offset | 41 | 49 | 46 | 41 | 36 |
| Fork Length (A2C) | 374 | 313 | 410 | 304 | 356 |
| Seatpost Diameter | Aero | Aero | Aero | Aero | Aero |
| Wheel Size | 700C | 700C | 700C | 700C | 700C |
| Tyre Max Width | 32mm | 32mm | 32mm | 32mm | 32mm |
| Seatpost Length | 350mm | 350mm | 350mm | 350mm | 350mm |
| Seatpost Offset | 14mm | 14mm | 14mm | 14mm | 14mm |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
