Mondince FM296 2025


c

Geometry

  49 52 54 56 58
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 319 450 368 459 418
Stack 556 471 649 691 717
Top Tube (effective) 443 588 641 568 526
Seat Tube C-C 483 620 503 490 561
Head Angle 68 69 79 77 86
Seat Angle 83 71 74 66 80
Head Tube 99 125 122 138 134
Chainstay 415 487 461 478 382
Wheelbase 1229 1010 926 1036 919
Front Centre 699 653 582 636 582
Standover 608 729 877 825 905
BB Drop 64 91 80 85 63
Fork Rake / Offset 55 41 50 58 44
Trail 66 74 68 76 76
Fork Length (A2C) 415 476 438 421 477
Seatpost Diameter 27.2mm 27.2mm 27.2mm 27.2mm 27.2mm
Wheel Size 700C/650B 700C/650B 700C/650B 700C/650B 700C/650B
Tyre Max Width 50/2.1'' 50/2.1'' 50/2.1'' 50/2.1'' 50/2.1''
Seatpost Length 350mm 350mm 350mm 350mm 350mm
Seatpost Offset 0 0 0 0 0
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
