| XS | S | M | L | XL | |
|---|---|---|---|---|---|
| Add to Compare | |||||
| Reach | 408 | 350 | 419 | 474 | 412 |
| Stack | 486 | 621 | 552 | 594 | 666 |
| Top Tube (effective) | 490 | 510 | 667 | 630 | 484 |
| Seat Tube C-C | 400 | 474 | 443 | 545 | 548 |
| Head Angle | 71 | 79 | 64 | 60 | 66 |
| Seat Angle | 84 | 80 | 70 | 64 | 72 |
| Head Tube | 100 | 104 | 171 | 147 | 237 |
| Chainstay | 501 | 394 | 446 | 501 | 403 |
| Wheelbase | 1034/1039 | 1049/1054 | 1066/1071 | 1081/1086 | 1092/1097 |
| Front Centre | 596 | 761 | 577 | 679 | 582 |
| BB Drop | 71 | 87 | 76 | 69 | 68 |
| BB Type | T47 | T47 | T47 | T47 | T47 |
| Fork Rake / Offset | 45/50 | 45/50 | 45/50 | 45/50 | 45/50 |
| Fork Length (A2C) | 395mm | 395mm | 395mm | 395mm | 395mm |
| Seatpost Diameter | 27.2mm | 27.2mm | 27.2mm | 27.2mm | 27.2mm |
| Wheel Size | 700/650B | 700/650B | 700/650B | 700/650B | 700/650B |
| Tyre Max Width | 50/2.1'' | 50/2.1'' | 50/2.1'' | 50/2.1'' | 50/2.1'' |
| Seatpost Length | 350/400 | 350/400 | 350/400 | 350/400 | 350/400 |
| Seatpost Offset | 0/14mm | 0/14mm | 0/14mm | 0/14mm | 0/14mm |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
