Geometry

  XXS XS S M L
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 363 437 457 458 434
Stack 514 507 479 598 512
Top Tube (effective) 432 444 633 589 555
Seat Tube C-T 458 439 453 608 458
Head Angle 82 80 61 75 69
Seat Angle 84 78 62 91 86
Head Tube 103 101 95 92 143
Chainstay 450 329 404 385 415
Wheelbase 908 1028 804 929 1031
Front Centre 551 544 613 729 669
BB Drop 66 59 59 54 78
BB Type Evo 386 Evo 386 Evo 386 Evo 386 Evo 386
Fork Rake / Offset 40 43 39 47 40
Fork Length (A2C) 387 332 389 363 309
Axle Spacing F 100x12x1.5 / R 142x12x1.5 F 100x12x1.5 / R 142x12x1.5 F 100x12x1.5 / R 142x12x1.5 F 100x12x1.5 / R 142x12x1.5 F 100x12x1.5 / R 142x12x1.5
Wheel Size 622 751 828 783 642
Tyre Max Width 30 27 26 28 31
Seatpost Offset 0 0 0 0 0
Rider Height <165 165-175 170-180 175-185 185>
Frame Weight 1784
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer
