Geometry

  12.5 15 17 18.5 20 22
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Top Tube (effective) 531 660 541 565 689 639
Top Tube (actual) 488 612 506 616 506 677
Seat Tube C-C 274 338 430 496 603 592
Head Angle 67 66 72 69 78 58
Seat Angle 86 86 59 64 67 64
Head Tube 94 115 141 101 126 188
Chainstay 343 502 482 400 389 379
Wheelbase 1060 977 1298 1007 1255 1227
Front Centre 652 573 709 791 677 612
Standover 661 694 714 827 684 925
BB Height 291 265 275 268 337 292
Fork Length (A2C) 508 545 574 517 546 474
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
