Geometry

  2 3 4 5
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 503 408 514 559
Stack 571 520 625 544
Top Tube (effective) 548 584 651 766
Seat Tube C-T 410 398 371 426
Seat Tube (effective) 327 427 524 469
Head Angle 62 64 67 60
Seat Angle 88 69 72 74
Head Tube 102 118 138 159
Chainstay 376 356 432 496
Wheelbase 1439 1248 1407 1260
Standover 649 763 649 614
BB Height 405 331 350 381
Fork Rake / Offset 45 51 50 42
Trail 157 138 118 114
Wheel Size 29"/27.5" 29"/27.5" 29"/27.5" 29"/27.5"
Max Post Insertion 200 314 311 323
Front Travel 189 179 158 156
Rear Travel 135 132 127 135
Data Source Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
