Geometry

  48 50.0 53 55.5 58 60.5
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 355 347 395 432 381 326
Stack 577 469 605 479 638 623
Top Tube (effective) 542 531 485 447 584 509
Seat Tube C-T 531 493 633 567 591 673
Head Angle 59 73 71 84 69 71
Seat Angle 81 67 79 66 76 61
Head Tube 87 119 137 117 144 202
Chainstay 480 398 353 362 440 448
Wheelbase 1008 877 820 1035 833 1036
Front Centre 570 529 694 616 581 589
Standover 801 656 641 788 739 929
BB Drop -62 -65 -75 -61 -69 -72
BB Height 329 304 305 238 283 324
Fork Length (A2C) 460 396 424 326 356 326
Handlebar Width 431 436 504 385 500 487
Stem Length 78 85 87 89 110 114
Crank Length 146 138 200 157 171 151
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
