Geometry

  40.5cm (16") 44.5cm (17.5") 49.5cm (19.5")
Add to Compare
Reach 408 459 461
Stack 563 595 737
Top Tube (effective) 609 648 771
Top Tube (actual) 667 535 588
Seat Tube C-T 413 520 575
Head Angle 60 54 58
Seat Angle 80 59 88
Chainstay 353 365 433
Wheelbase 1154 1036 1148
Front Centre 667 686 691
Standover 814 779 874
BB Drop -54 -65 -51
Front Travel 124 130 127
Rider Height 5' 3" - 5' 7" 5' 7" - 5' 11" 5' 11" - 6' 3"
Data Source Retailer Retailer Retailer

Measurements are in millimeters and degrees.
