Geometry

  XS S M L XL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 331 408 400 461 428
Stack 519 579 615 687 665
Top Tube (effective) 468 462 464 507 475
Seat Tube C-T 436 401 499 492 571
Head Angle 58 69 62 77 64
Seat Angle 65 82 63 64 74
Head Tube 108 132 155 144 189
Chainstay 449 464 389 372 347
Wheelbase 986 908 1056 1131 1019
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.

Image showing geometry measurements
