Geometry

  XXS XS S M L XL XXL
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 418 406 436 386 364 438 424
Stack 527 532 459 616 593 674 534
Top Tube (effective) 511 413 608 464 535 653 615
Seat Tube C-T 403 504 422 536 575 554 498
Head Angle 73 82 75 77 62 67 68
Seat Angle 86 84 75 73 62 65 88
Head Tube 66 85 86 129 111 136 180
Chainstay 371 338 428 423 421 434 393
Wheelbase 1149 965 1026 1078 1051 905 1029
Front Centre 574 645 664 472 677 513 532
Standover 727 756 793 614 665 930 861
BB Drop 89 63 69 72 60 62 73
Fork Rake / Offset 67 56 59 54 39 36 37
Trail 46 60 62 67 55 63 64
Fork Length (A2C) 328 405 357 428 420 431 402
Seatpost Offset 0 0 0 0 0 0 0
Stem Length 87 116 91 139 111 135 150
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
