Geometry

  430 465 500 515 530 540 550 560 575 595 620
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 378 305 389 366 429 388 324 315 372 384 472
Stack 600 473 433 638 625 535 473 606 598 552 722
Top Tube (effective) 495 587 548 571 578 474 622 554 530 474 721
Seat Tube C-T 385 409 443 423 518 589 451 513 498 469 630
Seat Tube C-C 406 450 509 426 438 437 566 653 555 635 528
Head Angle 66 61 70 78 67 74 86 79 62 61 73
Seat Angle 70 73 88 71 59 66 77 77 83 67 63
Head Tube 112 129 109 132 136 123 131 173 134 177 235
Chainstay 485 474 480 406 360 356 415 415 445 355 463
BB Drop 65 65 66 60 75 67 61 74 82 67 60
Fork Rake / Offset 44 42 42 55 51 47 45 54 43 54 38
Fork Length (A2C) 404 442 437 419 429 318 345 326 338 300 331
Data Source Cope form website Cope form website Cope form website Cope form website Cope form website Cope form website Cope form website Cope form website Cope form website Cope form website Cope form website

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
