| 420 | 440 | 465 | 470 | 500 | 515 | 530 | 540 | 550 | 560 | 575 | 595 | 620 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Add to Compare | |||||||||||||
| Reach | 360 | 403 | 346 | 402 | 374 | 320 | 428 | 420 | 450 | 358 | 449 | 374 | 346 |
| Stack | 488 | 604 | 521 | 624 | 540 | 449 | 440 | 540 | 571 | 488 | 635 | 512 | 672 |
| Top Tube (effective) | 563 | 572 | 576 | 524 | 493 | 561 | 437 | 622 | 528 | 630 | 610 | 530 | 537 |
| Seat Tube C-T | 390 | 486 | 525 | 414 | 444 | 586 | 423 | 494 | 509 | 495 | 652 | 643 | 717 |
| Head Angle | 60 | 61 | 76 | 79 | 66 | 72 | 85 | 72 | 58 | 68 | 61 | 72 | 86 |
| Seat Angle | 75 | 84 | 67 | 88 | 75 | 66 | 86 | 59 | 76 | 86 | 68 | 83 | 81 |
| Head Tube | 97 | 96 | 86 | 108 | 117 | 94 | 107 | 119 | 151 | 166 | 158 | 184 | 269 |
| Chainstay | 425 | 363 | 402 | 338 | 403 | 434 | 339 | 478 | 356 | 357 | 373 | 420 | 398 |
| Front Centre | 489 | 499 | 491 | 688 | 620 | 561 | 486 | 553 | 525 | 683 | 611 | 692 | 702 |
| BB Drop | 78 | 65 | 85 | 86 | 60 | 60 | 72 | 57 | 57 | 75 | 77 | 78 | 70 |
| Fork Rake / Offset | 37 | 50 | 49 | 41 | 46 | 48 | 51 | 38 | 39 | 45 | 46 | 35 | 44 |
| Fork Length (A2C) | 328 | 329 | 312 | 337 | 426 | 410 | 436 | 373 | 346 | 346 | 406 | 345 | 359 |
| Data Source | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer | Manufacturer |
Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
