Geometry

  Longish Long Longer
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 520 532 515
Stack 643 598 527
Top Tube (effective) 475 580 698
Seat Tube C-C 385 384 359
Head Angle 64 68 63
Seat Angle 62 90 84
Head Tube 88 116 107
Chainstay 425 - 441 425 - 441 425 - 441
Wheelbase 1155 - 1171 1175 - 1191 1195 - 1211
BB Drop 56 52 71
Axle Spacing Boost Boost Boost
Wheel Size 29, 27.5, 27.5+ 29, 27.5, 27.5+ 29, 27.5, 27.5+
Front Travel 100 - 120 100 - 120 100 - 120
Data Source Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
