Geometry

  S (Low) S (High) M (Low) M (High) L (High) L (Low) XL (High) XL (Low)
To view geometry data you must use a web browser that supports JavaScript. See: browser-update.org
Add to Compare
Reach 369 414 466 521 391 382 485 492
Stack 530 545 556 683 731 737 651 671
Top Tube (effective) 644 519 603 610 732 648 589 789
Seat Tube C-T 372 440 373 383 407 503 549 465
Head Angle 65.00° 65.50° 65.00° 65.50° 65.50° 65.00° 65.50° 65.00°
Seat Angle 80 75 84 89 73 90 84 72
Head Tube 113 83 90 110 123 92 103 130
Chainstay 410 351 494 488 458 356 486 473
Wheelbase 1327 1233 1221 1043 1124 1100 1466 1143
Standover 567 562 821 748 588 660 841 671
BB Drop 30 27 24 24 34 26 26 19
BB Height 342 358 312 386 379 377 339 291
Wheel Size 29" 29" 29" 29" 29" 29" 29" 29"
Data Source Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer Manufacturer

Standard measurements are in millimeters and degrees. The site attempts to recognize and convert other units back to standard - results may vary.
